Quad Bike / ATV Specs
Kawasaki Bayou 250 4x2 2006 specs
Kawasaki Bayou 250 4x2 2006 specs
Below are some specifications of the Kawasaki Bayou 250 4x2 2006 model
ATV Type :
Utility Quad Bikes
Engine Spec
Engine Detail :
228 cc, Air-cooled, four-stroke, single cylinder
Engine Capacity (cc / Ci ) :
228 cc / Unknown
Engine Type :
four-stroke
Engine Cooling :
Air-cooled
Engine Cylinders :
single cylinder
Bore Stroke(mm) :
69.0 mm x 61.0 mm
Compression Ratio :
8.9:1
Fuel System :
Mikuni VM24SS
Ignition :
Solid state with electronic ignition backup
Brakes
Brakes Front :
Dual drums
Brakes Rear :
Drum
Suspension
Front Suspension :
Independent Single A-arm 4.5 in travel
Suspension Rear :
Semi-independent Quad-Link with dual shocks 4.5 in travel
Dimensions and Weight
Length (mm / in.) :
1781 / 70.1
Width (mm / in.) :
1021 / 40.2
Ground Clearance (mm / in.) :
191 / 7.5
Wheelbase (mm / in.) :
1115 / 43.9
Dry Weight (Kg / Lbs.) :
183.3 / 404
Transmission (Gearbox) and Final Drive
Transmission :
Five-speed-plus reverse with automatic clutch , semi automatic
Final Drive :
Shaft
Tires and Rims
Tires Front :
AT21x8-9 tubeless
Tires Rear :
AT22x10-10 tubeless
Fuel
Fuel Tank Capacity (l / gal.) :
10 / 2.6
Racks and Payload
Rack Capacity Front (Kg / Lbs.) :
Unknown / 44
Rack Capacity Rear (Kg / Lbs.) :
Unknown / 66
Seats
Seat Height (mm / in.) :
729 / 28.7
Towing
Towing Capacity (Kg / Lbs.) :
Unknown / 450
Instrumentation
Instumentation :
Neutral indicator, reverse indicator,Fuel gauge
Lighting
Lighting :
25W x 2
Colours
Colors :
Hunter Green, Aztec Red
