2019 Yamaha Raptor 700 ATV Specs South Africa

2019 Yamaha Raptor 700 specs for South Africa:Racing Quad Bikes. Prices, reviews, where to buy.

Yamaha Raptor 700

Yamaha Raptor 700 2019

Make

Yamaha

Model

Raptor

Year

2019

Type

Racing Quad Bikes

Compare This Quad

Add to side-by-side comparison (up to 4 quads)

View Comparison

Engine Spec

Engine Capacity (cc / Ci ): 686 / 41.86

Engine Valves: SOHC

Valve Configuration: 4-valves

Total Valves: 4

Engine Type: 4-Stroke

Engine Cooling: Liquid / Air

Engine Cylinders: Single-Cylinder

Displacement To Weight CC: 1.63

Bore Stroke(mm): 102mm x 84mm

Bore Stroke(in): 4.02in. x 3.31in.

Compression Ratio: 10.0:1

Fuel System: Fuel Injected

Fuel Injector Size MM: 44

Fuel Type: Petrol

Ignition: Electric

Brakes

Brakes Front: Dual Hydraulic Disc

Brakes Rear: Hydraulic Disc

Suspension

Front Suspension: Independent Double Wishbone

A-Arm Skid Plate (Front): No

Suspension - Front Travel (mm / in.): 231 / 9.1

Front Adjustable Fork Pre-Load: Yes

Suspension Rear: Swing Arm

Suspension Rear - Material: Aluminum

A-Arm Skid Plate (Rear): No

Swing Arm Skid Plate: No

Rear Travel (mm / in.): 257 / 10.1

Rear Adjustable Shock Spring Pre-Load: Yes

Number of Rear Shock Absorbers: 1

Air Adjustable: No

Dimensions and Weight

Length (mm / in.): 1844 / 72.60

Width (mm / in.): 1156 / 45.5

Height (mm / in.): 1115 / 43.9

Ground Clearance (mm / in.): 239 / 9.4

Wheelbase (mm / in.): 1280 / 50.4

Wet Weight (Lbs. / Kg): 422 / 191.4

Transmission (Gearbox) and Final Drive

Transmission: Manual

Final Drive: 4X2

Drive line Modes: 1

Primary Drive - Rear Wheels: Chain

Hi / Low Range: No

Number Of Speeds: 5

Reverse: Yes

Tires and Rims

Tire Make: Maxxis

Tube / Tubeless: Tubeless

Tires Front: Maxxis AT 22 X 7-10

Front Tire Diameter (in): 22

Front Tire Width (in): 7

Front Rim Diameter (in): 10

Tires Rear: Maxxis AT 20 X 10-9

Rear Tire Diameter (in): 20

Rear Tire Width (in): 10

Rear Rim Diameter (in): 9

Rim Material: Aluminum

Rear Solid Axle: Yes

Fuel

Fuel Tank Capacity (l / gal.): 11 / 2.9

Seats

Seat Height (mm / in.): 831 / 32.7

Number Of Seats: 1

Seat Location: Driver

Seat Material: Vinyl

Seat Type: One-Piece

Seat Adjustable: No

Instrumentation

Fuel Level Warning Type: Light

Temperature Warning Type: Light

Lighting

Lighting: Halogen

Headlights: Standard

Halogen Headlights: Standard

Colours

Metallic: No

Comfort

Adjustable Levers: Standard

Exterior - Safety and Design

Bash Plate (Front): Yes

Bash Plate (Rear): No

Body Material: Plastic

Brush Guard: No

CV Boot Cover: No

Floor Board Location: Driver

Foot Peg Location: Driver

Folding Foot Pegs: No

Frame: Aluminum / Steel

Front Bumper: Standard

Front Fender: Standard

Full Length Skid Plate: No

Hand Grips: Standard

Hand Guards: No

Light Guard: No

Radiator Guard: No

Rear Bumper: Standard

Rear Fender: Standard

Rear Stabilizer Bar: No

Steering

Steering Type: Manual

Manufacturer and Warranty

Manufacturer Country: Japan

Recommend Minimum Age: 16

Parent Company: Yamaha
