2020 Honda FourTrax Recon ES ATV Specs South Africa

2020 Honda FourTrax Recon ES specs for South Africa:Utility Quad Bikes. Prices, reviews, where to buy.

Honda FourTrax Recon ES

Honda FourTrax Recon ES 2020

Make

Honda

Model

FourTrax

Year

2020

Type

Utility Quad Bikes

Compare This Quad

Add to side-by-side comparison (up to 4 quads)

View Comparison

Engine Spec

Engine Capacity (cc / Ci ): 229 / 13.97

Engine Valves: OHV

Valve Configuration: 2-valves

Total Valves: 2

Engine Type: 4-Stroke

Engine Cooling: Air

Engine Cylinders: Single-Cylinder

Engine Braking: Standard

Bore Stroke(mm): 68.5mm x 62.2mm

Bore Stroke(in): 2.7in. x 2.45in.

Compression Ratio: 9.2:1

Fuel System: Carburetor

Carburetor Size MM: 22

Carborator Count: 1

Fuel Type: Petrol

Ignition: Electric / Pull

Speed Governor: No

Brakes

Brakes Front: Dual Sealed Hydraulic Drum

Brakes Rear: Sealed Drum

Suspension

Front Suspension: Independent Double Wishbone

Suspension - Front Travel (mm / in.): 130 / 5.1

Front Adjustable Fork Pre-Load: No

Front Adjustable Rebound Damping: No

Suspension Rear: Swing Arm

Suspension Rear - Material: Steel

Swing Arm Skid Plate: No

Rear Travel (mm / in.): 124 / 4.9

Rear Adjustable Rebound Damping: No

Rear Adjustable Shock Spring Pre-Load: No

Number of Rear Shock Absorbers: 1

Air Adjustable: No

Dimensions and Weight

Length (mm / in.): 1905 / 75.00

Width (mm / in.): 1034 / 40.7

Height (mm / in.): 1069 / 42.1

Ground Clearance (mm / in.): 152 / 6

Wheelbase (mm / in.): 1130 / 44.5

Wet Weight (Lbs. / Kg): 370.1

GVWR (Kg / Lbs.): 370.1 / 816

Transmission (Gearbox) and Final Drive

Transmission: Manual / Automatic Clutch

Final Drive: 4X2

Drive line Modes: 1

Primary Drive - Rear Wheels: Shaft

Number Of Speeds: 5

Reverse: Yes

Tires and Rims

Tire Make: Maxxis

Tires Front: Maxxis 22 x 7-11

Front Tire Diameter (in): 22

Front Tire Width (in): 7

Front Rim Diameter (in): 11

Tires Rear: Maxxis 22 x 10-9

Rear Tire Diameter (in): 22

Rear Tire Width (in): 10

Rear Rim Diameter (in): 9

Rim Material: Steel

Fuel

Fuel Tank Capacity (l / gal.): 9.1 / 2.4

Fuel Tank Reserve (l / gal.): 2.3 / 0.6

Storage

Storage Capacity (Kg / Lbs.): 15 / 33

Fender Storage: Standard

Seats

Seat Height (mm / in.): 792 / 31.2

Number Of Seats: 1

Seat Location: Driver

Seat Material: Vinyl

Seat Type: One-Piece

Seat Adjustable: No

Lumbar Adjustment: No

Windshield

Tinted: No

Lighting

Lighting: Halogen

Headlights: Standard

Halogen Headlights: Standard

Colours

Metallic: No

Exterior - Safety and Design

Bash Plate (Front): Yes

Brush Guard: Yes

Cargo Bed Tilt: No

Floor Board Location: Driver

Folding Foot Pegs: No

Frame: Steel

Front Bumper: Standard

Front Fender Flairs: Standard

Front Fender: Standard

Front Stabilizer Bar: No

Hand Grips: Standard

Hand Guards: No

Light Guard: No

Power Outlet: Standard

Rear Bumper: Standard

Rear Fender: Standard

Rear Fender Flairs: Standard

Rear Stabilizer Bar: No

Snorkel Air Intake: Standard

Steering

Steering Type: Manual

Turning Circle: 8.5

Manufacturer and Warranty

Manufacturer Country: Japan

Recommend Minimum Age: 16

Parent Company: Honda

Warranty Info: 12 Limited
