2009 Arctic Cat 366 4x4 Automatic ATV Specs South Africa

2009 Arctic Cat 366 4x4 Automatic specs for South Africa:Utility Quad Bikes. Prices, reviews, where to buy.

Arctic Cat 366 4x4 Automatic

Arctic Cat 366 4x4 Automatic 2009

Make

Arctic Cat

Model

366

Year

2009

Type

Utility Quad Bikes

Compare This Quad

Add to side-by-side comparison (up to 4 quads)

View Comparison

Engine Spec

Engine Capacity (cc / Ci ): 366 / 22.33

Engine Valves: SOHC

Valve Configuration: 4-valve

Total Valves: 4

Engine Type: 4-Stroke

Engine Cooling: Air / Oil-Cooled

Engine Cylinders: Single-Cylinder

Engine Braking: Engine Braking System

Displacement To Weight CC: 0.64

Bore Stroke(mm): 81mm x 71.2mm

Bore Stroke(in): 3.19in. x 2.81in.

Fuel System: Carburetor

Fuel System Brand: Keihin

Carburetor Size MM: 34

Carborator Count: 1

Fuel Type: Petrol

Ignition: Electric / Pull

Brakes

Brakes Front: Hydraulic Disc

Brakes Rear: Hydraulic Disc

Linked Brake System Front to Rear: Standard

Suspension

Front Suspension: Independent Double A-Arm

A-Arm Skid Plate (Front): No

Suspension - Front Travel (mm / in.): 178 / 7

Front Adjustable Fork Pre-Load: Yes

Front Adjustable Rebound Damping: No

Suspension Rear: Independent Double A-Arm

Suspension Rear - Material: Steel

A-Arm Skid Plate (Rear): No

Rear Travel (mm / in.): 178 / 7

Rear Adjustable Rebound Damping: No

Rear Adjustable Shock Spring Pre-Load: Yes

Number of Rear Shock Absorbers: 2

Air Adjustable: No

Dimensions and Weight

Length (mm / in.): 2057 / 81.00

Width (mm / in.): 1118 / 44

Height (mm / in.): 1184 / 46.6

Ground Clearance (mm / in.): 254 / 10

Wheelbase (mm / in.): 1219.2 / 48

Dry Weight (Kg / Lbs.): 258.6 / 570

Transmission (Gearbox) and Final Drive

Transmission: Continuously Variable (CVT)

Transmission Make: Duramatic

Final Drive: Selectable 4X2 / 4X4

Drive line Modes: 2

Primary Drive Engine / Transmission: Belt

Primary Drive - Front Wheels: Shaft

Hi / Low Range: Yes

Reverse: Yes

Tires and Rims

Tire Make: Maxxis

Tires Front: AT 24 X 8-12

Front Tire Diameter (in): 24

Front Tire Width (in): 8

Front Rim Diameter (in): 12

Front Rim Width (in): 8

Tires Rear: AT 24 X 10-12

Rear Tire Diameter (in): 24

Rear Tire Width (in): 10

Rear Rim Diameter (in): 12

Rear Rim Width (in): 10

Rim Material: Steel

Rear Solid Axle: No

Fuel

Fuel Tank Capacity (l / gal.): 15.1 / 4

Storage

Storage Capacity (Kg / Lbs.): 34 / 75

Tool Bag Mount: Standard

Seats

Number Of Seats: 1

Seat Location: Driver

Seat Material: Vinyl

Seat Type: One-Piece

Seat Adjustable: No

Towing

Tow Hook: Standard

Rear Hitch: Receiver

Towing Capacity (Kg / Lbs.): 476.3 / 1050

Instrumentation

Digital Instrumentation: Standard

Trip Odometer: Standard

Voltage Meter: Standard

Clock: Standard

Fuel Level Warning Type: Gauge

Hour Meter: Standard

Speedometer: Standard

Lighting

Lighting: Halogen

Headlights: Standard

Halogen Headlights: Standard

Colours

Metallic: No

Exterior - Safety and Design

Bash Plate (Front): Yes

Body Material: Plastic

Brush Guard: Yes

CV Boot Cover: No

Floor Board Location: Driver

Folding Foot Pegs: No

Frame: Steel

Front Bumper: Standard

Front Fender Flairs: Standard

Front Fender: Standard

Front Stabilizer Bar: No

Hand Grips: Standard

Light Guard: No

Radiator Guard: Yes

Rear Fender: Standard

Rear Fender Flairs: Standard

Rear Stabilizer Bar: No

Shock Cover: No

Steering

Steering Type: Manual

Manufacturer and Warranty

Manufacturer Country: USA

Recommend Minimum Age: 16

Parent Company: Arctic Cat
