Can-Am DS 70 2020 specs
Can-Am DS 70 2020 specs
Below are some specifications of the Can-Am DS 70 2020 model
ATV Type :
Kids Quad Bikes
Introduction Year :
2008
Engine Spec
Engine Capacity (cc / Ci ) :
69 / 4.21
Engine Valves :
SOHC
Valve Configuration :
2-valves
Total Valves :
2
Engine Type :
4-Stroke
Engine Cooling :
Air
Engine Cylinders :
Single-Cylinder
Bore Stroke(mm) :
47mm x 40mm
Bore Stroke(in) :
1.85in. x 1.58in.
Fuel System :
Carburetor
Fuel System Brand :
Keihin
Carborator Count :
1
Fuel Type :
Petrol
Ignition :
Electric / Kick
Kill Switch Tether Cord :
Standard
Speed Governor :
Yes
Brakes
Brakes Front :
Dual Drum
Brakes Rear :
Drum
Suspension
Front Suspension :
Independent A-Arm
A-Arm Skid Plate (Front) :
No
Suspension - Front Travel (mm / in.) :
86 / 3.4
Front Adjustable Fork Pre-Load :
No
Front Adjustable Rebound Damping :
No
Suspension Rear :
Swing Arm
Suspension Rear - Material :
Steel
A-Arm Skid Plate (Rear) :
No
Swing Arm Skid Plate :
No
Rear Travel (mm / in.) :
160 / 6.3
Rear Adjustable Rebound Damping :
No
Rear Adjustable Shock Spring Pre-Load :
No
Number of Rear Shock Absorbers :
1
Air Adjustable :
No
Dimensions and Weight
Length (mm / in.) :
1518 / 59.76
Width (mm / in.) :
905 / 35.6
Height (mm / in.) :
935 / 36.8
Ground Clearance (mm / in.) :
211 / 8.3
Wheelbase (mm / in.) :
1000 / 39
Dry Weight (Kg / Lbs.) :
113 / 250
Transmission (Gearbox) and Final Drive
Transmission :
Continuously Variable (CVT)
Final Drive :
4X2
Drive line Modes :
1
Primary Drive Engine / Transmission :
Belt
Primary Drive - Rear Wheels :
Chain
Hi / Low Range :
No
Reverse :
Yes
Tires and Rims
Tire Make :
Duro
Tires Front :
Duro Thraser 19 x 7 - 8
Front Tire Diameter (in) :
19
Front Tire Width (in) :
7
Front Rim Diameter (in) :
8
Tires Rear :
Duro Power Trail 18 x 9.5 - 8
Rear Tire Diameter (in) :
18
Rear Tire Width (in) :
9.5
Rear Rim Diameter (in) :
8
Rim Material :
Steel
Rear Solid Axle :
Yes
Fuel
Fuel Tank Capacity (l / gal.) :
6 / 1.6
Storage
Front Storage Well :
Standard
Seats
Seat Height (mm / in.) :
685 / 27
Number Of Seats :
1
Seat Location :
Driver
Seat Material :
Vinyl
Seat Type :
One-Piece
Seat Adjustable :
No
Lighting
Lighting :
Halogen
Headlights :
Standard
Halogen Headlights :
Standard
Other Lights :
Standard
Colours
Metallic :
No
Comfort
Adjustable Throttle :
Standard
Exterior - Safety and Design
Bash Plate (Front) :
Yes
Bash Plate (Rear) :
No
Body Material :
Plastic
Brush Guard :
No
CV Boot Cover :
No
Floor Board Location :
Driver
Folding Foot Pegs :
No
Frame :
Steel
Front Bumper :
Standard
Front Fender :
Standard
Front Stabilizer Bar :
No
Full Length Skid Plate :
No
Hand Grips :
Standard
Hand Guards :
No
Handlebar Pads :
Standard
Light Guard :
No
Radiator Guard :
No
Rear Bumper :
Standard
Rear Fender :
Standard
Rear Stabilizer Bar :
No
Shock Cover :
No
Steering
Steering Type :
Manual
Manufacturer and Warranty
Manufacturer Country :
Canada
Recommend Minimum Age :
6
Parent Company :
Can-Am
